Performance

Rated Load (T)

1

Bucket rated capacity (M³)

0.45

Dumping Height (MM)

2450\3150

Lifting Height (MM)

3680\4350

Dumping Reach (MM)

800\1200

Max. Lifting weight (KG)

1000\500

Max. Excavation Force (KG)

1100\600

Max. Grade ability (°)

18

Max. Turning Angel (°)

29±1

Dimensions. &.Weight

Overall Length (MM)

4580

Overall Width (MM)

1260/1300

Overall Height (MM)

2450

Wheelbase (MM)

1580

Tire Spacing (MM)

1000

Min Ground Clearance (MM)

215

Net Weight (KG)

2840

Battery

No.of Battery Groups

12

Rated Voltage (V)

72

Transmission System

Hydraulic System

Motor No.

YQP5-72AF-48P

Voltage (V)

72

Power (W)

5000

Displacement (ML/R)

15

Rotating Speed (R/Min)

2000

 Walking System

Motor No.

YQP4-72A1-48P

Voltage (V)

72

Power (W)

4000x2

Rotating Speed (R/min)

2988

Tyres

Type

29*12.50-15

Working Pressure (Mpa)

0.3

Qty

4

Steering System

Type of Steering Hydraulic System

Full Hydraulic Steering System

System Pressure (Mpa)

16

Type of Steering Pump

Gear Pump

Steering Cylinder Bore (MM)

Φ63-35

Qty (PC)

2

Braking System

Service Brake

Drum Brake

Brake Drum (MM)

240

Parking Brake

Drum Brake

Dumping Cylinder-Bore (MM)

Φ100-50

Lifting Cylinder-Bore (MM)

Ø105-60

Lifting Cylinder Qty (PC)

1

Oil Capacity

Hydraulic Oil Tank (L)

54

Brake Fluid (L)

0.8

Qingzhou Ronggong machinery reserves the right of final explanation
